Product Summary
The 1N4001 is a plastic silicon rectifier, voltage - 50 to 1000 volts current - 1.0 Ampere.
Parametrics
1N4001 absolute maximum ratings: (1)Maximum Average Forward Rectified Current .375"(9.5mm)Lead Length at TA=75 ℃: 1.0 A; (2)Peak Forward Surge Current 8.3ms single half sine-wave superimposed on rated load(JEDEC method): 30 A; (3)Maximum Forward Voltage at 1.0A DC and 25 ℃: 1.1 V; (4)Maximum Full Load Reverse Current Full Cycle Average at 75 ℃ Ambient: 30 A; (5)Maximum Reverse Current at TA=25 ℃: 5.0 g A; (6)At Rated DC Blocking Voltage TA=100 ℃: 500 A; (7)Typical Junction capacitance: 15 PF; (8)Typical Thermal Resistance R KJA: 50 ℃J /W; (9)Typical Thermal resistance R K JL: 25 ℃J /W; (10)Operating and Storage Temperature Range TJ,TSTG: -55 to +150℃.
Features
1N4001 features: (1)Low forward voltage drop; (2)High current capability; (3)High reliability; (4)High surge current capability; (5)Exceeds environmentastandards of MIL-S-19500/228.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 1N4001 |
Fairchild Semiconductor |
Rectifiers Vr/50V Io/1A T/R |
Data Sheet |
|
|
||||||||||||
 |
1N4001 - 1N4007 |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
1N4001/1 |
Vishay Semiconductors |
Rectifiers Vr/50V Io/1A BULK |
Data Sheet |
Negotiable |
|
||||||||||||
|
1N4001/4 |
Vishay Semiconductors |
Rectifiers Vr/50V Io/1A T/R |
Data Sheet |
Negotiable |
|
||||||||||||
|
1N4001/L-1N4007/L |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
 |
1N4001/REEL |
Central Semiconductor |
Diodes (General Purpose, Power, Switching) Vr/50V Io/1A T/R |
Data Sheet |
Negotiable |
|
||||||||||||
|
1N4001_Q |
Fairchild Semiconductor |
Rectifiers Vr/50V Io/1A |
Data Sheet |
Negotiable |
|
||||||||||||
|
1N40017L |
Other |
|
Data Sheet |
Negotiable |
|
||||||||||||
