Product Summary
The M51132FP is a VCA IC developed as an electronic volume control for audio-visual equipment. The IC is used to process small analog signals at the stage before power amplifier. Right/left independent volume control or right/left simultaneous volume control can be selected by DC voltages. Its built-in pass through function, in combination with an ALC amplifier, offers the capability of automatic level control.
Parametrics
M51132FP absolute maximum ratings: (1)VCC supply voltage: 15.5V; (2)ICC circuit current: 40mA; (3)Pd power dissipation: 550mW; (4)Kθ thermal derating: 5.5mW/℃; (5)Topr operating temperature: -20 to 75℃; (6)Tstg storage temperature: -40 to 125℃.
Features
M51132FP features: (1)two control modes can be selected; (2)built-in reference supply voltage circuit output current 10mA typ; (3)maximum input 3.4Vrms typ; (4)low distortion; (5)good channel separation.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||
|---|---|---|---|---|---|---|---|---|---|---|
 |
 M51132FP |
Other |
|
Data Sheet |
Negotiable |
|
||||
| Image | Part No | Mfg | Description | |
Pricing (USD) |
Quantity | ||||
|
M51132FP |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
M51132L |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
M51134P |
Other |
|
Data Sheet |
Negotiable |
|
||||
|
M51137FP |
Other |
|
Data Sheet |
Negotiable |
|
||||
