Product Summary

The TS80C188EB2010 is a 16-BIT high-integration embedded processor. Unless specifically noted, all references to the TS80C188EB2010 apply to the 80C188EB, 80L186EB, and 80L188EB. References to pins that differ between the 80C186EB/80L186EB and the 80C188EB/80L188EB are given in parentheses. The "L" in the part number denotes low voltage operation. Physically and functionally, the "C" and "L" devices are identical.

Parametrics

TS80C188EB2010 absolute maximum ratings: (1)Storage Temperature: -65℃ to +150℃; (2)Case Temp under Bias: -65℃ to +120℃; (3)Supply Voltage with Respect to VSS: -0.5V to +6.5V; (4) Voltage on other Pins with Respect to VSS: -0.5V to VCC +0.5V.

Features

TS80C188EB2010 features: (1)Low-Power Static CPU Core; (2)Two Independent UARTs each with an Integral Baud Rate Generator; (3)Two 8-Bit Multiplexed I/O Ports; (4)Programmable Interrupt Controller; (5)Three Programmable 16-Bit Timer/Counters; (6)Clock Generator; (7)Ten Programmable Chip Selects with Integral Wait-State Generator; (8)Memory Refresh Control Unit; (9)System Level Testing Support (ONCE Mode); (10)Direct Addressing Capability to 1Mbyte Memory and 64Kbyte I/O; (11)Speed Versions Available (5V): 20MHz; (12)Available in Extended Temperature Range (-40℃ to +85℃); (13)Low-Power Operating Modes; (14) Available In: D80-Pin Quad Flat Pack (QFP), D84-Pin Plastic Leaded Chip Carrier (PLCC), D80-Pin Shrink Quad Flat Pack (SQFP).

Diagrams

TS80C188EB2010 block diagram
