Product Summary

The XC4003E-4PQ100C is a high-performance, high-capacity Field Programmable Gate Array (FPGA). The XC4003E-4PQ100C provides the benefits of custom CMOS VLSI, while avoiding the initial cost, long development cycle, and inherent risk of a conventional masked gate array. The result of thirteen years of FPGA design experience and feedback from thousands of customers, the XC4003E-4PQ100C combines architectural versatility, on-chip Select-RAM memory with edge-triggered and dual-port modes, increased speed, abundant routing resources, and new, sophisticated software to achieve fully automated implementation of complex, high-density, high-performance designs.

Parametrics

XC4003E-4PQ100C absolute maximum ratings: (1)VRRM: 3.3V; (2)Average On-State Current, IT(AV): 12mA; (3)I = Industrial, TJ: -40 to +100℃; (4)Speed Grade: -3; (5)Package Type: High Heat Dissipation Quad Flat Pack; (6)Number of Pins: 240.

Features

XC4003E-4PQ100C features: (1)System featured Field-Programmable Gate Arrays, Select-RAMTM memory: on-chip ultra-fast RAM with; synchronous write option; dual-port RAM option; Fully PCI compliant (speed grades -2 and faster); Abundant flip-flops; Flexible function generators; Dedicated high-speed carry logic; Wide edge decoders on each edge; Hierarchy of interconnect lines; Internal 3-state bus capability; Eight global low-skew clock or signal distribution; (2)networks; (3)System Performance beyond 80 MHz; (4)Flexible Array Architecture; (5)Low Power Segmented Routing Architecture; (6)Systems-Oriented Features, IEEE 1149.1-compatible boundary scan logic support; Individually programmable output slew rate; Programmable input pull-up or pull-down resistors; 12 mA sink current per XC4000E output; (7)Configured by Loading Binary File, Unlimited re-programmability; (8)Read Back Capability, Program verification; Internal node observability; (9)Backward Compatible with XC4000 Devices; (10)Development System runs on most common computer platforms, Interfaces to popular design environments; Fully automatic mapping, placement and routing; Interactive design editor for design optimization Product Specification.

Diagrams

XC4003E-4PQ100C block diagram

Image Part No Mfg Description Data Sheet Download Pricing
(USD)
Quantity
XC4003E-4PQ100C
XC4003E-4PQ100C


IC FPGA 100 CLB'S 100-PQFP

Data Sheet

Negotiable
