Product Summary

The LM725CH is an operational amplifier featuring superior performance in applications where low noise,low drift, and accurate closed-loop gain are required. With high common mode rejection and offset null capability, the LM725CH is especially suited for low level instrumentation applications over a wide supply voltage range.

Parametrics

LM725CH absolute maximum ratings: (1)Supply Voltage:±22V; (2)Internal Power Dissipation:500 mW; (3)Differential Input Voltage :±5V; (4)Input Voltage : ±22V; (5)Storage Temperature Range :-65°C to +150°C; (6)Lead Temperature(Soldering, 10 Sec.):260°C; (7)Maximum Junction Temperature:150°C; (8)Operating Temperature Range:0°C to +70°C.

Features

LM725CH features : (1)High open loop gain 3,000,000; (2)Low input voltage drift 0.6 μV/°C; (3)High common mode rejection 120 dB; (4) Low input noise current 0.15 pA/Hz; (5)Low input offset current 2 nA; (6)High input voltage range ±14V; (7)Wide power supply range ±3V to ±22V; (8) Offset null capability; (9)Output short circuit protection.

Diagrams

LM725CH Pin Configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
LM725CH/NOPB
LM725CH/NOPB

IC OP AMP INSTRUMENTATION TO99-8
Data Sheet
Negotiable
