Product Summary
The LT1009S8 is a precision trimmed 2.5V shunt regulator diode featuring a maximum initial tolerance of only ±5mV. The low dynamic impedance and wide operating current range enhances its versatility. The 0.2% reference tolerance is achieved by on-chip trimming which not only minimizes the initial voltage tolerance but also minimizes the temperature drift.
Parametrics
LT1009S8 absolute maximum ratings: (1)Reverse Current:20mA; (2)Forward Current:10mA; (3)Storage Temperature Range:– 65°C to 150°C; (4)Lead Temperature (Soldering, 10 sec): 300°C; (5)Operating Temperature Range:0°C to 70°C.
Features
LT1009S8 features: (1)Maximum Initial Tolerance: 0.2%; (2)Guaranteed Temperature Stability; (3)Maximum 0.6Ω Dynamic Impedance; (4) Wide Operating Current Range; (5) Directly Interchangeable with LM136 for Improved Performance; (7)No Adjustments Needed for Minimum Temperature Coefficient.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 LT1009S8 |
|
IC VREF SHUNT 2.5V 8-SOIC |
Data Sheet |
|
|
||||||||||
|
LT1009S8#PBF |
|
IC VREF SHUNT 2.5V 8-SOIC |
Data Sheet |
|
|
||||||||||
|
LT1009S8#TR |
|
IC VREF SHUNT 2.5V 8-SOIC |
Data Sheet |
|
|
||||||||||
|
LT1009S8#TRPBF |
|
IC VREF SHUNT 2.5V 8-SOIC |
Data Sheet |
|
|
||||||||||
