Product Summary

The NS0013-TLF is a 10/100 base pulse transformer for pcmcia.

Parametrics

NS0013-TLF specifications: (1)Insertion loss (dB Max) 0.3-100 MHz: -1.1; (2)Return loss (dB Min) 0.5-30MHz: -18, 40MHz: -15.5, 50MHz: -13.5, 60-80 MHz: -10; (3)Cross talk (dB Min) 0.3-100 MHz: -38.

Features

NS0013-TLF features: (1)Half port and single port designs for maximum layout flexibility; (2)Low profile packages from 0.09 Inch(2.39MM) TO 0.078 Inch(1.98) For pccard and cardbus applications; (3)Compatible with intel,tdk,qdi,and ics Transceivers; (4)Storage temperature range: -40℃ to +125℃.

Diagrams

NS0013-TLF dimensions
